Retail, Convenience and Grocery Stores

Resindek® Flooring Packs Resilience in Retail, Convenience and Grocery Store Replenishment

Restocking brick-and-mortar storefronts requires versatility, high storage density, and fast turnarounds. Don’t be slowed down by cracked or degrading concrete or noisy bar grating on your mezzanine, elevated work platform, or pick module.  With ResinDek® flooring panels, you can maximize your elevated surfaces’ durability and longevity under heavy rolling pallet jack loads, autonomous mobile robots (AMRs), or automatic guided vehicles (AGVs). And you can minimize associates’ fatigue with ResinDek ergonomic flooring panels.

Research conducted by The Ohio State University’s Institute for Ergonomics found that an elevated platform with ResinDek flooring, compared to a concrete platform, decreased tibial shock by 7.8% at the work rate walking speed, and decreased tibial shock by 10.6% at the work rate walking speed on bar grate.

Why Choose ResinDek Flooring Panels:

  • Engineered for rolling pallet jack, carts and robotic fleets
  • Minimize associates’ fatigue with ergonomic properties – The Ohio State University’s Institute for Ergonomics found that an elevated platform with ResinDek flooring, compared to a concrete platform, decreased tibial shock by 7.8% at the work rate walking speed, and decreased tibial shock by 10.6% at the work rate walking speed on bar grate.
  • With a variety of ResinDek panels and coatings we can provide a hybrid flooring solution that is extremely cost-effective and tailored to meet the needs of each individual project

ResinDek® Floor Panels for Retail, Convenience and Grocery Stores

ResinDek composite engineered flooring panels have the proven structural integrity to support dynamic and static pallet jack load limits from 2,000 – 8,000 lbs (910 – 3360 kg) and the rigorous demands of robotic traffic such as AGVs and AMRs.

We recommend that a minimum of 20-gauge (0.9 mm) corrugated metal B Deck be used on all ResinDek flooring projects (except for Xspan®) and a minimum of 18 gauge (1.2 mm) when live and dead loads exceed 2,500 Ibs. (1135 kg)  ResinDek Xspan and Xspan FR do not require a corrugated metal deck. ResinDek flooring panels LD, MD and HD are ¾” (19 mm) thick, ResinDek Max is 1-1/2″ (38 mm) thick, and ResinDek Xspan and Xspan FR are 1-1/8″ (28mm) thick.

For Use with Corrugated B-Deck:

ResinDek LD
3/4″ (19mm) Thick Panel
Robot Loads up to:
500 lbs/230 kg
Pallet Loads up to:
2,000 lbs/910 kg

ResinDek LD

ResinDek MD
3/4″ (19mm) Thick Panel
Robot Loads up to:
2,000 lbs/910 kg
Pallet Loads up to:
3,500 lbs/1,590 kg

ResinDek MD

ResinDek HD
3/4″ (19mm) Thick Panel
Robot Loads up to:
4,000 lbs/1,815 kg
Pallet Loads up to:
4,500 lbs/2,045 kg

ResinDek HD

ResinDek WR
3/4″ (19mm)Thick Panel
Robot Loads up to:
500 lbs/230 kg
Pallet Loads up to:
2,000 lbs/910 kg

ResinDek WR

ResinDek MAX
1-1/2” (38mm) Thick Panel
Robot Loads up to:
6,000 lbs/2,275 kg
Pallet Loads up to:
8,000 lbs/3,360 kg

ResinDek MAX

No Corrugated B-Deck Required (Single Panel Solution):

ResinDek HD
3/4″ (19mm) Thick Panel
Robot Loads up to:
4,000 lbs/1,815 kg
Pallet Loads up to:
4,500 lbs/2,045 kg

ResinDek HD

ResinDek Xspan / Xspan FR
1-1/8” (28mm) Thick Panel
Robot Loads up to:
2,500 lbs/1,135 kg
Pallet Loads up to:
3,000 lbs/1,365 kg

ResinDek Xspan & FR

For Use with a Sub Floor:

ResinDek ReShield
¼” (6mm) Thick Panel
Robot Loads up to:
3,000 lbs /1,365 kg
Pallet Loads up to:
3,500 lbs /1,590 kg

ResinDek ReShield

Optional Coatings & Finishes

For Heavy Equipment, Storage, Rolling Carts & Pallet Jacks

Gray Diamond Seal® Coating

Gray Diamond Seal®
ESD Coating

MetaGard® GVT Steel Decking Surface

Unfinished

For AGV & AMR Robotic Traffic

TriGard®
ESD Ultra Coating

TriGard®
ESD Coating

MetaGard® SST Steel Decking Surface

Related Documents & Case Studies

CASE STUDY

3PL’s Platform Optimized for Mobile Robots

CASE STUDY

ResinDek Flooring Provides Ergonomic Benefits

ResinDek Flooring Panels Inside a Distribution Center

Discover how ResinDek mezzanine flooring panels can be customized for different load capacities, types of traffic, and required floor finish.
